FPS 2160 Details
High-end Class AB amplifier.
Direct mode available for quality active amplification. Thermo-controlled ventilation. Compatible with High-Cap.
Advantages:
- Symmetrical design: Audiophile Quality
- Progressive controlled cooling system: Regulates the amplifier temperature
- Insulated Gate Bipolar Transistor (IGBT): Audiophile and powerful
- Direct mode: The audio signal is directly amplified
- High-pass, low-pass and band-pass crossovers: Adjustable from 50Hz to 5kHz
- Pseudo-balanced input: No parasite
- Controlled cooling system: Air flow control
- Safety terminal: Cable and sheath complete integration
- Stable into 2 Ohms stereo, High-Cap compatible
Specification:
CEA 2006 (4 Ohms, ≤1% THD N, 14.4 Volts) | 2x105W |
| Nominal Power | 2x160W into 2 Ohms with 0.11% THD |
| Nominal Power (bridged mode) | 1x360W into 4 Ohms with 0.4% THD |
| Adjustable high-pass crossover from | 50Hz to 5kHz |
| Adjustable low-pass crossover from | 50Hz to 5kHz |
| Adjustable band-pass crossover from | 50Hz to 5kHz |
| Direct Mode: Protections | short-circuit, direct current, thermal overload, polarity reversal |
