CC-2 is a small and powerful amplifier with a RMS poweroutput of 2 x 170 Watts. In 4 ohm mono bridge-connection, it puts out all of340 Watts.
- Built-in low-pass filter for subwoofers, variable between 50 and 500 Hz.
- The high-pass filter is also variable between 50 and 500Hz.
- Built-in protection circuits shut down the amplifier inthe event of overloads.
- High level input with AUTO-start function makes it easierto connect to factory installed head units.
- Bass EQ variabel fron 0 till 6dB.
- THD at 5W, 1 kHz: <0,02%
- Damping factor: >150
- Signal to noise ratio, A-weighted: 110 dB
Specifications:
Number of channels | 2 |
Amplifier class | AB |
Mono bridge mode 4 ohm | 340 Watt |
Output power in 2 ohm | 2 x 170 Watt |
Output power in 4 ohm | 2 x 110 Watt |
Damping factor | > 150 |
S/N ratio, A-weighted | > 110 dB |
Frequency range | 10 Hz - 50 kHz |
Input impedance | 6Kohm |
Input impedance, High level | 45ohm |
High pass filter | 50 -500 Hz |
Low pass filter | 50 -500 Hz |
Grand bass filter | Bass EQ 6 dB @ 60 Hz |
Low level output | No |
High level input with auto start | Yes |
Power consumption (idle) | 0.5 A |
Power consumption (max) | 43 A |
Rec. power cable | 16 sq mm ( 5 AWG ) |
Fuses | 2 x 20 A |
Dimension (W x D x H) | 129 x 260 x 51 mm (5.07" x 10.2" x 2") |
Weight | 1.87 kg |
